Special Order Item: Y

Brewer Assist Power Procedure Table, Gunmetal

SKU: 9627000-22

Status: Out of Stock

Each (1)

Special Ordered Via Quote



The Brewer Assist Power Procedure Table™ can be lowered down to 19″ making wheel chair transfers effortless.  The 450 lb weight capacity and the additional 5″ leg extension accommodates larger patients more comfortably for safer clinical outcomes.  As with all Brewer Power Tables, the Brewer Assist comes with our standard 3 year warranty and 12 standard seamless upholstery colors.

Product Benefits

  • Assist Control: Easily move the procedure table to the exact position needed with backrest, seat, footrest and height adjustments.
  • 450 lb weight capacity
  • Standard 3 year warranty
  • Most technologically advanced
  • Lowers to 19″ for lateral patient transfer
  • Exclusive three point pivot headrest
  • Seamless easy to clean upholstery
  • Footrest extends an additional 5″
  • Intuitive foot controls
  • 12 standard colors with optional upgrades
  • Wide assortment of accessories available



More Info

More Info

Advanced Safety

  • Safety release actuators
  • Safe extra-low voltage actuators
  • 19″ (48.3 cm) low height
  • 40″ (101.6 cm) maximum height
  • Leg rest extends an additional 5″ (12.7 cm)
  • Adjustable three-point pivot headrest
  • Easy-to-clean seamless upholstery
  • 18″ (45.7 cm) or 21″ (53.3 cm) paper dispenser



Patient Comfort

  • Easy lateral wheelchair transfers
  • Infinitely adjustable headrest
  • Extendable leg rest
  • Multi-density, bolstered support upholstery



Table Specifications

  • 450 lb (204 kg) weight capacity
  • Standard three-year warranty
  • Standard adjustable stirrups
  • Standard foot control
  • Height: 19″ – 40″ (48.3 cm – 101.6 cm)
  • Length: 69″ (175.3 cm)
  • Length with headrest & leg rest extended: 80″ (203.2 cm)
  • Length in upright position: 40” (101.6 cm)
  • Width: 28″ (71.1 cm)
  • Leg rest: 16.6″ x 11.25″ (42.2 cm x 27.9 cm)
  • Headrest: 13″ x 11″ (33 cm x 27.9 cm)
  • Tilt range / Trendelenburg: to 30º
  • Base: 24″ W x 36″ L (61 cm x 91.4 cm)
  • 115 VAC, 60 Hz
  • 12 standard upholstery color options
  • CAL-133 fire resistant upholstery available in 4 colors
  • Premium, plush upholstery available in 5 colors
  • Custom colors available



Certification

All Brewer products conform to US and Canadian electrical and medical industry codes and regulations and meet or exceed industry requirements.

UL 60601-1



Accessories

  • 99497 – Grab Bars (Qty. 2) **
  • 99499 – Articulating Arm Board **
  • 99500 – Hand Pendant
  • 99501 – Side Seat Rails (Qty. 2)
  • 99502 – Universal Socket Clamp (Qty. 1)
  • 99504 – Deluxe Articulating Knee Crutches (Pair – Right & Left) ***
  • 100253 – Urology Drain Pan Kit
  • 102024 – Brewer Welch Allyn® Exam Light IV Bracket (plant installed)
  • 102025 – Brewer Welch Allyn® Exam Light IV Bracket (field installed)

**   Requires two side seat rails (one order of 99501)

*** Requires two side seat rails (one order of 99501) and two universal socket clamps (two orders of 99502)

Mfg Item No.

Mfg Item No.

7000 – Brewer Assist Power Procedure Table
7500 – Brewer AssistPRO Programmable Power Procedure Table
